YV100X 系列KV8-M665L-00X YV100X X轴Z-R信号线
No. Part No. Part Name Q'ty Remarks Date Revised No.
1 KV7-M9221-00X PLATE PUSH IN 1
2 KV7-M9222-00X BRACKET,PUSH IN 1
3 KV7-M9223-00X HOLDER CYL. 1
4KV7-M9224 -00X COLLAR 1
5 KV7-M9225-00X BRACKET,HOLDER 1
6 KV7-M9226-00X COLLAR,HOLDER CYL. 1
7 KV7-M9227-00X BLOCK,COLLAR 1
8 KV7-M9228-00X BRG. 1 F694ZZ
9 KV7-M9229-00X CYLINDER 1
10 KU0-M9227-00X ROD END 1 Y-PDA10
11 $SC4-M5A SPEED CONTROLLER 2
12 91317-04006 BOLT HEX.SOCKET HEAD 2
12-1 90159-04J03 SCREW,W/WASHER 8 X4M 920068
13 91317-04008 BOLT HEX.SOCKET HEAD 2
1491317-04 014 BOLT HEX.SOCKET HEAD 1
15 91317-04016 BOLT HEX.SOCKET HEAD 1
15-1 KV7-M2251-00X NYLOCK BOLT(M4X16) 30 X2 M960110
16 92907-04200 WASHER PLAIN 1
No. Part No. Part Name Q'ty Remarks Date Revised No.
1 KV7-M9201-00X BRACKET,MOTOR 1
2 KV7-M9202-00X STAY,ADJUST 1
3 KV7-M9203-00X SHAFT 1 2
4 KV7-M9205-00X PULLEY 1 1
5 KV7-M9206-00X WASHER 1
6 90K50-52175U AC SERVO MOTOR 1
6-1 90K50-523D5U AC SERVO MOTOR Y3 M940017
7 KV7-M920F-00X BEARING 4
8 99009-10400 CIRCLIP 2
9 KV7-M9204-00X SHAFT 2 1
10 KV7-M9207-00X FLANGE 1 1
11 KV7-M9208-00X FLANGE 2 1
12 KV7-M9209-00X PULLEY 2 1
13 KV7-M9211-00X HOUSING 1
14 KV7-M9212-00X COLLAR 2 1
15 KV7-M9213-00X NUT 1
16 KV7-M9214-00X SCREW 1
17 KV7-M9215-00X JOINT 1
18 KV7-M9217-00X FLANGE 1
19 KV7-M9218-00X SPRING 1
20 KV7-M921C-00X ROLLER 1
21 K01-M1739-10X BEARING 3 2 6905ZZ
22 99009-42500 CIRCLIP 1
23 99009-25400 CIRCLIP 1
24 KV7-M9219-00X STOPPER 1
25 KV7-M921B-00X BOLT,STOPPER 1
26 KV7-M920D-00X DOG 1
27 KV7-M920E-00X BRACKET 1
28 KV7-M653A-00X SENSOR,1 ASSY 1 L=600
29 KV7-M920A-00X PLATE 445 1
30 KV7-M920C-00X STAY,F 1
31 KV7-M921A-00X BELT 1
32 91317-04008 BOLT HEX.SOCKET HEAD 2
33 91317-04010 BOLT HEX.SOCKET HEAD 14
34 91317-04012 BOLT HEX.SOCKET HEAD 1
35 91317-04020 BOLT HEX.SOCKET HEAD 2
36 91317-05012 BOLT HEX.SOCKET HEAD 16
37 91317-05014 BOLT HEX.SOCKET HEAD 4
38 91317-05016 BOLT HEX.SOCKET HEAD 2
38-1 KV7-M2663-00X NYLOCK BOLT(M5X16) X1 99/2 M920139
39 91317-05020 BOLT HEX.SOCKET HEAD 24
40 91317-06060 BOLT HEX.SOCKET HEAD 1
41 92A08-03006 SET SCREW 3 M3X6
42 92907-04200 WASHER PLAIN 2
43 92907-06200 WASHER PLAIN 1
44 92990-04200 WASHER PLAIN 2
No. Part No. Part Name Q'ty Remarks Date Revised No.
1 KV7-M9171-00X PLATE 1,LOCATION 2
1-1 KV7-M9171-01X PLATE 1-1,LOCATION 1 Y3 99/7 M960046
2 KV7-M9172-00X HOLDER LOCATE PIN 2
2-1 KV7-M9172-01X HOLDER LOCATE PIN Y3 99/2 M960046
3 KV7-M9173-00X PLATE 2,LOCATION 1
4 KV7-M9174-00X PIN 1,LOCATION 1
5 KV7-M9174-10X PIN 2,LOCATION 1
6 KV7-M9179-A0X CYLINDER ASSY 1
7 KV7-M9177-00X GUIDE 2
7-1 KV7-M9177-01X GUIDE:BSR 1575SL Y3 99/7 M960046
8 KV7-M9175-00X BRACKET,JOINT 2
8-1 KV7-M9175-01X BRACKET,JOINT Y3 99/7 M960046
9 KV7-M9176-00X COLLAR,JOINT 2
10 KV7-M9178-00X BRACKET,CYLINDER 2
11 SC4-M5A SPCON 4
12 91317-03005 BOLT HEX.SOCKET HEAD 14
13 91317-04006 BOLT HEX.SOCKET HEAD 5
13-1 90159-04J03 SCREW,W/WASHER 8 X4 M920068
14 91317-04008 BOLT HEX.SOCKET HEAD 3
15 92A08-03004 SET SCREW 2 M3X4
16 95304-03600 NUT HEXAGON 4
17 92904-03200 WASHER,PLAIN 4
No. Part No. Part Name Q'ty Remarks Date Revised No.
1 KV7-M9281-00X PLATE,SUB STOPPER 1
1-1 KV7-M9281-01X PLATE,SUB STOPPER X1 99/6 M960059
2 KV7-M9282-00X STOPPER,SUB 2
3 KV7-M9283-00X CYL.,YMDA16X35 2
4KV7-M9284 -00X BRKT.,SENSOR-3 4
4-1 KV7-M9284-01X BRKT.,SENSOR-3 1 X3 99/7 M960039
5 KM0-M655F-10X SENSOR,1-3 4
6 $SL4-M5 JOINT 5
7 91314-03005 BOLT HEX.SOCKET HEAD 9
8 91317-03012 BOLT HEX.SOCKET HEAD 9
9 91317-04008 BOLT HEX.SOCKET HEAD 4
10 91317-04040 BOLT HEX.SOCKET HEAD 4
11 KV7-M9281-10X PLATE-2,SUB STOPPER 1
12 KV7-M9284-00X BRKT.,SENSOR-3 4
12-1 KV7-M9284-01X BRKT.,SENSOR-3 1 X3 99/7 M960039
13 KH4-M655F-20X SENSOR 1-3 2
13-1 KU0-M655F-20X SENSOR,1-3 2 X2 99/7 M960040
14KV7-M9161-00X PALTE,STOPPER 1
15 KV7-M9162-00X BRKT.,STOPPER 1
16 KV7-M9163-00X STOPPER 1
17 KV7-M9164-00X BRKT.,CYLINDER 1
18 KV7-M9165-00X CYLINDER PDAS 1 6X40
19 KV7-M9166-00X GUIDE 1 LWL9 R80B
20 KG2-M9188-01X COLLAR 1
21 $SC4-M5A SPEED CONTROLLER 2
22 $UEF JOINT 1
23 91317-03005 BOLT HEX.SOCKET HEAD 2
2491317-03006 BOLT HEX.SOCKET HEAD 4
25 91317-03008 BOLT HEX.SOCKET HEAD 4
26 91317-04006 BOLT HEX.SOCKET HEAD 2
26-1 90159-04J03 SCREW,W/WASHER 8 X4 M920068
27 91317-04020 BOLT HEX.SOCKET HEAD 2
28 91317-05010 BOLT HEX.SOCKET HEAD 2
29 92907-03200 WASHER PLAIN 2
30 95304-03600 NUT HEXAGON 2
31 KV7-M9285-00X SPACER
No. Part No. Part Name Q'ty Remarks Date Revised No.
1 KV7-M9261-00X PLATE 1,LINK 1
2 KV7-M9262-00X PLATE BOARD CLAMP 2
3 KV7-M9263-00X PLATE 2,LINK 1
4 KV7-M9264-00X LINK 3
5 KV7-M9265-00X SPACER,COLLAR 3
6 KV7-M9266-00X COLLAR 1 6
7 KV7-M9267-00X COLLAR 2 3
8 KV7-M9268-00X PIN 3
9 KV7-M9269-00X CYLINDER 1
10 KV7-M926A-00X JOINT,CYL. 1
11 KV7-M926B-00X COLLAR,JOINT 2
12 KV7-M926C-00X STOPPER,CYLNDER 1
13 KV7-M926D-00X JOINT,CYL.BRKT. 1
14 KV7-M926E-00X BRKT.,CYL. 1
15 98904-03004 SCREW BINDING HEAD 8
16 KV7-M926G-00X BOLT,BUTTON HEAD 2
17 91317-04014 BOLT HEX.SOCKET HEAD 5
18 92907-03200 WASHER PLAIN 2
19 92907-04600 WASHER PLAIN
No. Part No. Part Name Q'ty Remarks Date Revised No.
1 KV7-M9231-00X PLATE,EDGE CLAMP 2
1-1 KV7-M9231-01X PLATE,EDGE CLAMP 2 Z3 M960025
2 KV7-M9232-00X PLATE 3,GUIDE 2
2-1 KV7-M9232-01X PLATE 3,GUIDE 2 Z3 M960025
3 KV7-M9233-00X GUIDE 2 2
4 KV7-M9234-00X SPACER,GUIDE 1
5 KV7-M9235-00X PLATE,LINK 6
6 KV7-M9236-00X SHAFT,LINK 1
6-1 KV7-M9236-01X SHAFT,LINK 1 Z3 M960025
7 KV7-M9237-00X CYLINDER PBSA 2 10X5
8 KV7-M9238-00X JONIT,CYL. 2
9 KV7-M9239-00X BRKT.,CYL. 2
10 KV7-M923A-00X COLLAR,JOINT 2
11 KV7-M923B-00X BRG 12 MR84ZZ
12 KV7-M923C-00X BRG 6 F683ZZS
13 KV7-M923D-00X COLLAR,CLAMP PLATE 8
13-1 KV7-M923D-01X COLLAR,CLAMP PLATE 8 Z3 M960025
14 $TSH4-M5M JOINT 2
15 91317-03006 BOLT HEX.SOCKET HEAD 8
16 91317-03008 BOLT HEX.SOCKET HEAD 30
17 91317-03010 BOLT HEX.SOCKET HEAD 8
18 98904-03004 SCREW BINDING HEAD 6
19 KV7-M9130-00X GUIDE 2-1 1
19-1 KV7-M9130-01X GUIDE 2-1 1 Z3 M960025
20 KV7-M9130-10X GUIDE2-2
No. Part No. Part Name Q'ty Remarks Date Revised No.
1 KV7-M9101-00X STAY,FOOT 4
1-1 KV7-M9101-01X STAY,FOOT 4 Z2 99/9 M970075
2 KV7-M9102-00X PLATE 1 2
3 KV7-M9103-00X PLATE 2 2
4 KV7-M9106-00X BRKT.1,EXT.FRAME 1
5 KV7-M9107-00X BRKT.2,EXT.FRAME 1
6 KV7-M9108-00X BRKT.3,EXT.FRAME 1
7 KV7-M9109-00X BRKT.4,EXT.FRAME 1
8 KV7-M9105-00X BRKT.,SPLINE 1
9 KV7-M9104-00X PLATE 3 2
10 KV7-M9116-10X GUIDE 2
10-1 90K71-0L0280 LM RAIL,15(250) 2 X1 M9X0050
11 KV7-M9115-10X PLATE,LINEAR 2
12 KV7-M9111-01X BRKT.,COLLAR 1
13 KG7-M9110-01X COLLAR,W 3
14 KV7-M9110-00X COLLAR 2,W 2
15 KV7-M9118-00X PLATE,BRG. 4
16 KG7-M9119-00X BRG 6200ZZ 2
17 KV7-M9132-10X BALL SCREW W 2
18 KV7-M9113-00X STAY,FRAME 2
19 KV7-M9114-00X BRKT.,GUIDE 2
20 KV7-M9121-00X FRAME,CONV.FIXED 1
21 KV7-M9122-00X FRAME CONV.MOVING 1
22 KV7-M9127-00X FRAME 1,EXT. 2
23 KV7-M9128-00X FRAME 2,EXT. 2
24 KV7-M9123-00X GUIDE 1 4
25 KV7-M9126-00X GUIDE 1-1 4
26 KV7-M9124-00X PLATE 1,GUIDE 1
27 KV7-M9125-00X PLATE 2 GUIDE 1
28 KV7-M9126-10X GUIDE 1-2 4
29 KM7-M9113-00X GUIDE 1,END 2
30 KM7-M9114-00X GUIDE 2,END 2
31 KG7-M912A-00X BRACKET SENSOR 1
32 KV7-M9151-00X DAMPER 1,W 2
33 KV7-M9152-00X DAMPER 2,W 2
34 KV7-M9129-00X BELT 1,CONVEYOR 2
35 KV7-M9144-00X BRKT.3,SENSOR 1
36 KG7-M9133-00X PLATE LOCATE PIN 2
37 KG7-M9135-00X PLATE EDGE 2 4
38 KG7-M9136-00X PLATE EDGE 3 2
39 KH2-M9121-00X BEARING 4
40 KV7-M4886-00X MOTOR ASSY.6 1 CONV.MO
41 KM0-M655F-10X SENSOR,1-3 1
42 KM0-M9182-00X PLATE GUIDE 1
43 KG7-M9183-00X BRACKET BELT 1
44 KM8-M9189-00X GUIDE 1
45 KG7-M9127-00X STOPPER LOCATE PIN 1
46 KV7-M9188-00X BELT 1 1305-3GT-6
47 KV7-M9192-00X PLATE,IDLER 1
48 KV7-M9185-00X HOUSING,SHAFT 1
49 KV7-M9190-00X HANDLE 1
50 KV7-M9191-00X SHAFT 1 1
51 KV7-M9193-00X LEVER,CLAMP 1
52 KU0-M9194-00X WASHER 1
53 99009-15400 CIRCLIP : 1
54 KV7-M9195-00X BRKT.,HOUSING 1
55 KV7-M9196-00X SHAFT 2 1
56 KH4-M655F-20X SENSOR 1-3 2
56-1 KU0-M655F-20X SENSOR,1-3 2 X2 99/7 M960040
57 KV7-M9140-00X PULLEY,CONVEYOR 12
58 KV7-M9141-00X SHAFT,PULLEY 4
59 KV7-M9143-10X SPLINE 1 2
60 KV7-M9142-00X PILLEY 1,MOTOR 1
61 KH2-M9105-10X PULLEY MOTOR 4 3GTP30
62 KV7-M9146-00X BELT 2 300-3GT-9
63 KG2-M9105-00X PULLEY 1 SPLINE 1
64 KG2-M9108-10X COLLAR,CONVEYOR 1
65 KV7-M91B2-00X BRKT.,SENSOR 1
66 KG7-M9111-01X PULLEY 1 1
67 KG7-M9112-01X PULLEY 2 1
68 KG7-M9113-01X PULLEY 3 1
69 90K50-4W072W AC SERVO MOTOR 1
69-1 90K55-4W072W AC SERVO MOTOR X3 M960053
70 KV7-M9147-00X BRKT.,MOTOR W 1
71 KV7-M9148-00X BRKT.,TENSION 2
72 K94-M9316-00X BEARING 4 608ZZ
73 KV7-M9149-00X COLLAR,BRG. 2
74 KG7-M9115-00X BELT W AXIS 1
75 KH2-M655E-00X SENSOR,1-2 1
75-1 KV7-M653A-20X SENSOR 1 ASSY:L=300 1 X1 98/12 M8Y0077
76 KV7-M9150-00X DOG 1,ORIGIN 1
77 KV7-M9155-00X BRKT.,SENSOR SHAFT 2
78 KV7-M9156-00X SENSOR SHAFT 1
78-1 KV7-M9156-01X SENSOR SHAFT 1 Y2 99/12 M9X0012
79 KV7-M9157-00X BRKT,4,SENSOR 1
79-1 KV7-M9157-01X BRKT.4,SENSOR 1 Y3 99/7 M960040
80 KV7-M910A-00X STAY1.FRAME. 2
81 KV7-M910B-00X STAY2.FRAME. 2
