YAMAHA YV100X PHILIPS SMT NOZZLE

日期：2011/4/22 17:22:00

YAMAHA YV100X PHILIPS SMT NOZZLE

YAMAHA YV100X PHILIPS SMT NOZZLE - smtrc - 深圳市仁创机电设备有限公司博客

Part Number (OEM)

Description

KV8-M71U1-002
KV8-M71U1-001
KV8-M7WK-A00
KV8-M71N1-A00
KV8-M71N2-A00
KV8-M71N3-A00
KV8-M7WK-A00
KV8-M71U6-001
KV8-M71U7-100
KV8-M71U5-100
K46-8527-C0X
KV8-M7WK-A00
KV8-M7710-A0X
KV8-M7720-A0X
KV8-M7730-A0X
KV8-M7740-A0X
KV8-M7760-00X
KV8-M7WL-A00

YAMAHA YV100X PHILIPS SMT NOZZLE - TYPE 71F ( 2 HOLE )
YAMAHA YV100X PHILIPS SMT NOZZLE - TYPE 72F ( ' X' )
TYPE 7WF ( ?1.2 / ?0.6) (FNC)
TYPE 71F ( 2 HOLE )
TYPE 72F ( ' X' )
TYPE 73F
TYPE 7WF (?1.2/?0.6)
NZ. HOUSING
SPRING
SCREW
FILTER
TYPE 7WF (?1.2 / ?0.6)
YAMAHA YV100X PHILIPS SMT NOZZLE 71A (1.2X0.8)
YAMAHA YV100X PHILIPS SMT NOZZLE 72A (1.7X0.94)
73A
74A
76A (MELF)
7WA (1.2X0.6)

YAMAHA YV100 YVL88 PHILIPS EMERALD TOPAZ SMT NOZZLE

Part Number (OEM)

Description

KMO-M711A-02X
KMO-M711A-02X
KMO-M711B-00X
KMO-M711C-00X
KMO-M711D-00X
KMO-M711E-00X
KMO-M711F-00X
-
KMO-M711A-02X
-

YAMAHA YVL88 YV100 SMT NOZZLE PHILIPS EMERALD TOPAZ - A (TYPE 31)
YAMAHA YVL88 YV100 SMT NOZZLE PHILIPS EMERALD TOPAZ - A (TYPE 31) - 'X'
B (TYPE 32-1)
C (TYPE 32-2)
D (TYPE 33)
E (TYPE 34)
A (TYPE 31) - ?1.2 / (ROUND TIP) SPRING LOADED
A (TYPE 31) - 'X' SPRING LOADED

YAMAHA NOZZLE HOLDER PHILIPS EMERALD TOPAZ

Part Number (OEM)

Description

--
KV8-M7106-70
--

YV100II SHAFT NOZZLE HOLDER
YV100X SHAFT NOZZLE HOLDER
YVL88 SHAFT

YAMAHA SHAFT NOZZLE PHILIPS EMERALD TOPAZ

Part Number (OEM)

Description

KV8-M7135-A0X
KM9-M7106-00X

SHAFT HEAD ASSY
SHAFT HEAD ASSY

YAMAHA YG200 SMT NOZZLE

Part Number(OEM)

Description

KV8-M71N1-A0	YAMAHA YG200 71F ASSY SMT NOZZLE (201F)
KV8-M71N2-A0	YAMAHA YG200 72F ASSY SMT NOZZLE (202F)
KV8-M71N9-A0	YAMAHA YG200 79F ASSY SMT NOZZLE (209F)
KV8-M71N3-A0	73F ASSY NZ.(203F)
KV8-M87XD-A0	73F-D ASSY NZ.(203F-D)
KGT-M7710-A0	201A ASSY NZ.
KGT-M7720-A0	202A ASSY NZ.
KGT-M7790-A0	209A ASSY NZ.
KGT-M7730-A0	203A ASSY NZ.
KGT-M77XD-A0	203A-D ASSY NZ.
KGT-M7760-A0	206A ASSY NZ.

YAMAHA YG100 SMT NOZZLE

Part Number(OEM)	Description
KGS-M7710-A1X	NOZZLE 211A ASSY.
KGS-M7720-A1X	NOZZLE 212A ASSY.
KGS-M7730-01X	NOZZLE 213A
KGS-M7740-A1X	NOZZLE 214A ASSY.
KGS-M7750-A1X	NOZZLE 215A ASSY.
KGS-M7760-01X	NOZZLE 216A
KGS-M7790-A1X	NOZZLE 219A ASSY.
KV8-M711N-A0X	NOZZLE & SHAFT ASSY.
KV8-M71N1-A1X	NOZZLE 71F ASSY.
KV8-M71N2-A1X	NOZZLE 72F ASSY.
KV8-M71N3-A0X	NOZZLE 73F ASSY.
KV8-M71U5-00X	SCREW
KV8-M71U8-00X	BLOCK, NOZZLE
KV8-M712N-A0X	NOZZLE & SHAFT ASSY.
KV8-M71N9-A1X	NOZZLE 79F ASSY.
KV8-M713N-A0X	BLOCK & SHAFT ASSY.

YAMAHA YV88X PHILIPS EMRALD X SMT NOZZLE

Part Number (OEM)

Description

KGA-MT1N1-AOX

KGA-M71N1-A0X
KGA-MT1N2-AOX
KGA-M71N2-A0X
KGA-M71N3-A1X
KGA-M71N4-A0X
KGA-M71N5-A0X

KV7-M710M0-AOX

KGA-MT1N1-AOX-T
KGA-MT1N2-AOX-T

KV8-M77WL-AOX>

YAMAHA YV88X SMT NOZZLE PHILIPS EMRALD ASSY - TYPE 61F (2 HOLES)

YAMAHA YV88X SMT NOZZLE PHILIPS EMRALD ASSY - TYPE 61F (2 HOLES)
YAMAHA YV88X SMT NOZZLE PHILIPS EMRALD ASSY - TYPE 62F (0.92 X 1.75) 'X'
TYPE 62F (0.92 X 1.75) 'X'
TYPE 63F
TYPE 64F
Y TYPE 65F

YV88X NOZZLE HOLDER ASSY

NZ. TIP 61F (2 HOLES)
NZ. TIP-TYPE 62F (0.92 X 1.75)

7WL ASSY (?1.2 / 0.6)

YAMAHA PHILIPS YV112 COMET SMT NOZZLE

Part Number (OEM)

Description

KG2-M7191-100
KG2-M7191-200
KG2-M7191-300
KG2-M7191-400
KG2-M7191-500
----------

YAMAHA YV112 SMT NOZZLE PHILIPS TYPE 1 ? 0.9/ ? 0.5
YAMAHA YV112 SMT NOZZLE PHILIPS TYPE 2 ? 1.4/ ? 0.8
TYPE 3 ? 3.0/ ? 2.0
TYPE 4 ? 6.0/ ? 4.0
TYPE 5 ?10.0/ ? 8.0
9 HOLES

YAMAHA KV6-M7113 HSD DISPENDING NOZZLE PHILIPS

Part Number (OEM)

Description

KV6-M7113-1XX
KV6-M7113-2XX
KV6-M7113-3XX
KV6-M7113-4XX
KV6-M7113-5XX
KV6-M7113-6XX
KV6-M7113-XXX
KV6-M7113-XXX
KV6-M7113-XXX

YAMAHA YMH KV6-M7113 HSD DISPENDING NOZZLE PHILIPS 2D/2S ?0.7/ ?0.4 P=0.9
YMH KV6-M7113 HSD DISP. NZ. 2D/2S ?0.8/ ?0.5 P=1.3
YMH KV6-M7113 HSD DISP. NZ. 2D/2S ?1.3/ ?0.9 P=1.8
YMH KV6-M7113 HSD DISP. NZ. 1D/1S ?0.7/ ?0.4
YMH KV6-M7113 HSD DISP. NZ. 1D/1S ?0.8/ ?0.5
YMH KV6-M7113 HSD DISP. NZ. 1D/1S ?1.5/ ?1.1
YMH KV6-M7113 HSD DISP. NZ. 2D/2S ?0.7/ ?0.4 P=0.8
YMH KV6-M7113 HSD DISP. NZ. 1D/1S ?1.5/ ?1.1
YMH KV6-M7113 HSD DISP. NZ. 1D/1S ?1.65/ ?1.25

YAMAHA PHILIPS YV64D DISPENDING NOZZLE

Part Number (OEM)

Description

KG3-M7113-40X
KM4-M7113-10X
KM4-M7113-20X
KM4-M7113-30X
KM4-M7113-40X
KM4-M7113-50X

YAMAHA YV64D DISPENDING NOZZLE PHILIPS 2D/2S ? 0.7/ ? 0.4 P=0.8 (1608)
YV64D DISP NZ. 2D/2S ? 0.8/ ? 0.5 P=1.0(2125,3216)
YV64D DISP NZ. 1D/2S ? 0.6/ ? 0.3 (1608 & 2125)
YV64D DISP NZ. 1D/2S ? 0.8/ ? 0.5 (CONNECTOR)
YV64D DISP NZ. 1D/2S ID:? 1.5 ** (SOP & QFP)
YV64D DISP NZ. 1D/2S ID:? 1.5 ** (QFP & PLCC)

YAMAHA YV86D/YV100D DISPENDING NOZZLE PHILIPS

Part Number (OEM)

Description

K37-M7113-10X
K37-M7113-00X
K37-M7113-20X
K37-M7113-40X

YAMAHA YV86D YV100D DISPENDING NOZZLE PHILIPS 1D/2S (FOR ADHESIVE)
YV86D/YV100D 2D/2S (FOR ADHESIVE)
YV86D/YV100D 1D/1S(FOR SOLDER PASTE)
YV86D/YV100D 2D/2S(FOR 1608 CHIPS)

YAMAHA PHILIPS YMH SMT NOZZLE

Part Number (OEM)

Description

K38 - M7113 - H00
K38 - M7113 - B03
K38 - M7113 - C00
K38 - M7113 - D01
K38 - M7113 - E02

YMH NZ. ? 1.1X0.7 / ? 0.4
YMH NZ. ? 1.8X1.1 / ? 0.8
YMH NZ. ? 3.0 / ? 2.0
YMH NZ. ? 5.0 / ? 3.5
YMH NZ. ? 1.1 / ? 0.7

YAMAHA PHILIPS YM51VM11 SMT NOZZLE

, ,

Part Number (OEM)

Description

KG9 - M7113 - 100
KG9 - M7113 - 200
KG9 - M7113 - 300

YM51VMII NZ. S, COMP. ? 3.0 / ? 2.0
YM51VMII NZ. M ? 10.0 / ? 7.0
YM51VMII NZ. L ? 15.0 / ? 12.0

YAMAHA PHILIPS YM84 SMT NOZZLE

Part Number (OEM)

Description

KH - M7113 - C00
KH - M7113 - B00

YM 84 NZ. ID : ? 0.7 (TYPE 2)
YM 84 NZ. ID : ? 2.0 (TYPE 8)
